32ch 4 Sata port NVR With 16ch PoE
0 32ch PoE NVR, 4 sata ports, support 4k video in, 16ch PoE Ports.- SKU: NVR4K32H4-16P
- Categories:Network Video Recorder, POE NVR
Key feature:
- Support Ultra 265/H.265/H.264 video formats
- 32-channel input
- Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
- VGA and HDMI independent outputs provided
- Up to 8 Megapixels resolution recording
- 4 SATA HDDs, Up to 10TB for each HDD
- Various fisheye dewarping modes for live view and playback for both web interface and GUI
- Support for 12V Power output
- Plug & Play with up to 16 independent PoE network interfaces
- ANR technology to enhance the storage reliability when the network is disconnected
- Support cloud upgrade
Specification:
| Model | NVR4K32H4-16P |
| Video/Audio Input | |
| IP Video Input | 32-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network | |
| Incoming Bandwidth | 160Mbps |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| Protocols | P2P, UPnP, NTP, DHCP, PPPoE |
| Video/Audio Output | |
| HDMI: | |
| 4K (3840×2160@30), 1920X1080@60, 1920X1080@50, 1600X1200@60, 1280X1024@60, 1280X720@60, | |
| 1024X768@60 | |
| HDMI/VGA output | VGA: |
| 1920X1080@60, 1920X1080@50, 1280X1024@60, 1280X720@60, 1024X768@60 | |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 32-ch |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
| Decoding | |
| Decoding format | Ultra 265, H.265, H.264 |
| Live view/Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 2 x 4K@30, 4x 4MP@30, 5 x 3MP@30, 8 x 1080P@30, 16 x 720P@30, 32 x D1@30 |
| Hard Disk | |
| SATA | 4 SATA interfaces |
| Capacity | up to 10TB for each HDD |
| External Interface | |
| Network Interface | 1 RJ45 10M/100M/1000M self-adaptive Ethernet Interface |
| Serial Interface | 1 x RS485 |
| Front panel: 2 x USB2.0 Rear panel: 1 x USB3.0 | |
| USB Interface | |
| Alarm In | 16-ch |
| Alarm Out | 4-ch |
| Power Output | 12 VDC |
| PoE | |
| Interface | 16 independent 100 Mbps PoE network interfaces |
| Max 30W for single port | |
| Max Power | Max 240W in total ( 12.5W for each ) |
| Supported Standard | IEEE 802.3af/at |
| General | |
| 100 ~ 240 VAC | |
| Power Supply | Power Consumption: ≤ 20 W( without HDD ) |
