6MP 3072*2048 Resulution Turret ip camera, 2.8mm F1.0 Lens, build-in mic/PoE
| Model | IP6MLB37EFC |
| Camera | |
| Image Sensor | 1/3” CMOS Sensor |
| Effective Pixels | 3072*2048 |
| Electronic Shutter | AUTO, 1/25s ~ 1/100000s |
| Min. Illumination | 0.01Lux@F1.2(AGC ON), 0Lux IR on |
| Day/Night | Auto/Color/(B/W)/Timing |
| WDR | Digital WDR |
| White Balance | Auto/Indoor/Outdoor |
| BLC | Support |
| DNR | 2D/3D DNR |
| Other | Human body and Vehicle detection,Motion Detection, Privacy Mask, Mirror, flip |
| Encode | |
| Embedded Solution | SSC30KQ |
| Video Standard | H.264/H.265 |
| Video Resolution | Main Stream:25fps@ 6MP(3072*2048) ；25fps@ 5MP(2592*1944)；25fps@ 4MP(2560*14400) |
| Sub Stream: D1/VGA(640×480)/360P@25fps, etc. | |
| Video Bitrates | 32Kbps – 6Mbps, VBR/CBR |
| Audio Standard | G.711-u/G.711-a |
| OSD Overlay | Title and Time overlay |
| Leds | |
| Leds | 2PCS Integrated white & infrared LED(Dual-light) |
| Light Distance | 25-30 M |
| Lens | |
| Focal length | HD 2.8mm F1.0/F1.6 lens |
| Functions | |
| POE, Mic | |
| Network Services | |
| Protocol | HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
| P2P | Yes |
| Web | IE , Firefox, etc. |
| Media | CMS, Android, IOS |
| ONVIF | 17.06 compatible |
| General | |
| Network Port | 1-RJ45, 100Mbps, |
| Power Supply | POE ,12 VDC ± 10% |
| Power Consumption | < 8 W |
